U-Line H-1036 User Manual

PAGE 6 OF 18 0316 IH-1036
KEY DESCRIPTION
A Power Cord
B Side Cover
C Power
D Control Panel
E Green Key 'Random Length' – Dispenses tape
F Keys for 11 presets of tape length
G +2 (inches) key – presets length by 2"
H
'Short Length' – Sets one length of tape shorter
'Long Length' – Sets one length of tape longer than the first one
I Top Heater Switch
L Top Heater
M Water Reservoir
N Water Bottle
Q Colored Indicators
10 Water Reservoir
11 Bottle Holder
12 Top Heater 24V
13 Brush
14 Complete water tank without Top Heater and without brush
15 Knives (2)
16 Rolls (2)
17 Upper Paper Plate
18 20mm Diam. Roll
19 Roll Guide Plate
+2
°C
100°
8O°
44
40
36
32
28
24
20
16
12
8
4
10 11
16 17 18 19
15
13
14
N
Q
F
12
19
A
D
C
E
H
B
M L
G
I
