U-Line PURELL ES6 User Manual

PAGE 3 OF 9 0623 IH-10632
INSTALLATION CONTINUED
1
-800-295-551
0
uline.com
Figure 10
Fig u r e 11
Figure 7
Figure 8
Figure 9
5. Check label inside dispenser before installing.
(See Figure 7)
NOTE: ES6 SOAP = soap dispenser
ES6 SAN = hand sanitizer dispenser
6. Match label on refill with label on dispenser.
(See Figure 8)
7. Remove refill cap and push the new refill into
dispenser until it clicks in place. (See Figure 9)
8. Close dispenser cover. The green status light will
blink after closing, indicating the dispenser is ready
to use. (See Figure 10)
9. Place palms approximately 2" below dispenser.
Product will dispense within one second of sensor
activation. (See Figure 11)

U-Line PURELL ES6 Specifications

General

Brand	U-Line
Model	PURELL ES6
Category	Dispenser
Language	English
