U.S. Products AGITATOR 16 User Manual

07-6
3
Agitator
™
16 / 18 Clean & Restore
FORM NO. 56041707
BASE ASSEMBLY
Item Ref. No. Qty Description
1 56171095 2 Bearing, Flange NOTE 2
2 56220072 1 Fitting, 1/8npt X 1/4 Barb
3 56249505 2 Wheel
4 56456560 1 Hose, 15”
5 56365548 1 Lock Pin Assy NOTE 2
6 1 Wsh, Flt SAE 5/8
7 2 Wsh, Flt SAE 1/4
8 1 Scr, Pan Phil 8-32 X .62
9 1 Nut Stop Elastic 1/4 – 20 Hex
10 2 Nut, Hex Nyl Loc SS 1/4-20
11 1 Scr, Pan Phil 10-24 X 1.00
12 1 Nut, Hex Nyl Loc-Thin 10-24
13 1 Nut, Hex Nyl Loc-Thin 5/8-11
14 1 Nut, Hex Nyl Loc-Thin SS 10-24
15 1 Nut, Hex Nyl Loc-Thin 8-32
16 2 Wsh, Flt SAE SS #8
17 1 Scr, Pan Phil SS 10-24 X .50
18 1 Wsh, Flt SAE SS 3/8
19 1 Pin, Cotter Hair
20 2 Scr, Pan Phil SS 8-32 X .38
21 1 Scr, Pan Phil Plastite 10-14 X .75
22 2 Pin, Cotter Hair .0915 X .375
23 1 Pin, Spr .12 X .56
24 1 Screw 1/4 – 20 X 1 3/4 – Hex St Cap
25 1 Pin, Clevis .50 X 2.75
26 2 Scr, Hex Loc SS 1/4-20 X 4.50
27 2 Scr, Pan Phil Type A 10 X .50
28 2 Scr, Hex SS 1/4-20 X 2.25
29 2 Wsh, Flt SS .260 X 1.000 X .074
30 1 Nut, Conduit Lock 1/2-14
31 56009097 2 Nut, Push Cap 1/2
32 5 Scr, Pan Phil Plastite 10-14 X .50
33 56200573 1 Gasket, Ring 1.75x2.75x.19
34 56220055 1 Plug
35 56228142 2 Spring, Compression
Item Ref. No. Qty Description
36 56260071 1 Terminal Block
38 56265031 1 Clip, Rod
39 56265033 2 Mount, Pump
40 56109548 1 Knob, Brush Adjustment
41 56265057 1 Axle
42 56265071 1 Gasket, Exhaust
43 56265073 2 Pin, Pivot
44 56265103 1 Rectifi er, 35 Amp (D1)
45 56265111 1 Adjustment Rod Weldment
46 56265119 1 Latch, Adjustment
47 56265020 1 Base, Extractor, 16
56265120 1 Base, Extractor, 18
48 56265172 1 Panel, Exhaust
49 56265224 1 Pump 115V (M3) (Agitator 16)
56266027 1 Pump 115V (M3) (Agitator 18 Clean & Restore)
50 56266029 1 Linkage Weldment, 18 NOTE 2
51 See Brush Assembly Pages
52 56266048 1 16 ST Nozzle Assy (Agitator 16) NOTE 1
52 56266046 1 18 W/R Nozzle Assy (Agitator 18 Clean & Restore) NOTE 1
53 56266051 1 Nozzle Bracket
54 56266060 1 Quick Disconnect Bracket
55 56266079 1 Shoe Assembly, 16
56266077 1 Shoe Assembly, 18
56 56266086 1 18” W/R Front Nozzle Assembly
(Agitator 18 Clean & Restore) NOTE 1
57 56398606 1 Spring, Ext .50 X 6.25
59 3 Clamp, Hose SAE #4
60 56109566 1 Elbow, Solution Hose
61 56109503 1 Double Barb Assy
62 56266097 1 Lever-Brush Adjustment NOTE 3
63 56265239 1 Knob NOTE 3
64 56002916 1 Wsh-Flt SAE SS 10 NOTE 3
65 56201448 1 Spring-Compression NOTE 3
66 56003761 1 Scr-Soc Hd SS 10-32 x 1.50 NOTE 3
** 11143A 1 Kit, Base Assy Hardware
* = Not Shown
** = Optional, Not Included
NOTE 1: Refer to “BASE ASSEMBLY (NOZZLE ASSEMBLIES)” for replacement parts.
NOTE 2: These items are only used on the Agitator 18 Clean & Restore model 56266116.
NOTE 3: These items are only used on the Agitator 16 model 56266115.
10-12

U.S. Products AGITATOR 16 Specifications

General

Brand	U.S. Products
Model	AGITATOR 16
Category	Floor Machine
Language	English
