Agitator
™
16 / 18 Clean & Restore
FORM NO. 56041707
BASE ASSEMBLY [NOZZLE ASSEMBLIES]
Item Ref. No. Qty Description
56266086 1 18” W/R Front Nozzle Assembly (Agitator 18 Clean & Restore)
56266046 1 18 W/R Nozzle Assy (Agitator 18 Clean & Restore)
1
# 51208A 1 Metering Tip, Turquoise (2.15 oz / gal)
# 52828A 1 Metering Tip, Tan (1.25 oz / gal)
# 52829A 1 Metering Tip, Orange (1.70 oz / gal)
# 52831A 1 Metering Tip, Pink (3.00 oz / gal)
2# 56220043 1 Solution Feed Hose
3# 56266049 1 Nipple, 1/8npt X 1.25
4# 56266055 1 Manifold, Plug 1/4
5# 56266083 1 Manifold, Nozzle
6# 56314578 2 Body, Nozzle Qjja
7# 56317064 2 Nozzle, Spray #1
8# 56369632 2 Elbow, 90 Street
9# 56470138 1 Barb, 90 Elbow 1/4 X 1/4npt
10# 56740214 1 Bushing,Reducer
11# 56742317 1 Nipple, 1/4-18
12# 56756364 1 Clamp- Hose Sae #4
13# 56900027 1 Tee, Female Union
14# 56266030 1 Manifold, Nozzle
15# 56266062 1 Elbow, Female
16# 56317064 2 Nozzle, Spray #1
17# 56900024 1 Elbow,90 Male 45 Flared
56266048 1 16 ST Nozzle Assy (Agitator 16)
18# 56260841 1 7.00 Hose
19# 56742317 1 Nipple, 1/4-18
20# 2 56265037 1 Valve, Solenoid (L1 / 115V)
21# 56266083 1 Manifold, Nozzle
22# 56266085 2 Nozzle, Spray #2
23# 56314578 2 Body, Nozzle Qjja
24# 56369632 2 Elbow, 90 Street
25# 56470138 1 Barb, 90 Elbow 1/4 X 1/4npt
26# 56756364 1 Clamp- Hose Sae #4
27# 56900027 1 Tee, Female Union
# = Revised or new since last update
