U.S. Products AGITATOR 16 User Manual

07-6
7
Agitator
™
16 / 18 Clean & Restore
FORM NO. 56041707
BRUSH ASSEMBLY
Item Ref. No. Qty Description
1 56262558 1 Sheave, Poly-V
2 4 Scr, Hex 1/4-20 X .50
3 4 Wsh, Flt SAE 1/4
4 2 Scr, Soc Set Loc 5/16-18 X .31
5 56009191 3 Scr, Pan Phil Plastite 10-14 X .50
6 56265024 1 Belt, Poly V
7 56265043 1 Clip, Brush Retainer
8 56265047 1 Belt Guard
9 56265075 1 Motor, 115 Vdc, 1/3 Hp (M2)
10 56265091 1 Cover, Pulley
11 56266032 1 Brush Assembly 16
56266031 1 Brush Assembly 18
12 56265204 1 Bearing / Spindle Kit
** 11144A 1 Kit, Brush Assy Hardware
* = Not Shown
** = Optional, Not Included
