07-6
11
Agitator
™
16 / 18 Clean & Restore
HANDLE SYSTEM 18
FORM NO. 56041707
Item Ref. No. Qty Description
1 55502A 1 Knob-Solution Flow Module (Agitator 18 Clean & Restore)
2 56324272 1 Switch, Rocker (S2)
3 6 Wsh, Flt SAE SS 1/4
4 4 Scr, Pan Phil SS 1/4-20 X 2.50
5 2 Scr, Pan Phil SS 1/4-20 X 2.75
6 56009095 1 Nut, Conduit Lock 1/2-14
7 56265056 1 Circuit Breaker W/Boot (F1)
8 56220001 1 Switch, Rocker (S1)
9 56266124 1 Handle
10 56266043 1 Main Cable Assembly
11 56266074 1 Cord, Pigtail (Agitator 18 Clean & Restore)
* 56265162 1 Cord, Power 14/3 SJT (Agitator 16)
12 56266089 1 Wire Assy, Handle
13 56266090 1 Wire Assy, S1_To_F1
14 56486112 1 Clamp,P
15 40147a 1 Power Cord Assy (Agitator 18 Clean & Restore)
16 52504a 1 Variable Flow Control (Agitator 18 Clean & Restore / S3)
17 56323136 1 Strain Relief
** 11145A 1 Kit, Handle Assy Hardware
* = Not Shown
** = Optional, Not Included
HANDLE SYSTEM
11-6
