07-6
13
Agitator
™
16 / 18 Clean & Restore
RECOVERY SYSTEM
FORM NO. 56041707
Item Ref. No. Qty Description
1 56324497 2 Cage, Float
2 56416593 4 Plug Button 1.00
3 805USP 1 Cover Chain
4 4 Wsh, Flt SAE SS 1/4
5 1 Scr, Pan Phil SS 8-32 X .50
6 1 Nut, Hex Nyl Loc SS 8-32
7 2 Scr-Hex SS 10-24 X 2.00
8 4 Scr, Pan Phil SS 1/4-20 X 175
9 1 Scr, Pan Phil Type A 10 X .50
10 2 Wsh, Flt SS .219 X .500 X .047/.062
11 56002836 2 Nut Hex Nyl Loc SS 10-24
12 56265134 1 Duct, Float
13 56265163 1 Gasket
14 56266120 1 16” Recovery Tank Assembly
56266121 1 18” Recovery Tank Assembly
15 56266068 1 Upper Recovery Hose Assembly
16 56266080 1 Hose, Drain 1.5 Inch
17 56266096 1 Recovery Lid
18 56266098 1 Gasket, Dome
19 56266106 1 Plastic Tube
20 1 Clamp, Hose SAE #24
21 56391690 1 Ball, Float
22 56009096 2 Wsh Flt .193X.875X.060
** 11146A 1 Kit, Recovery Tank Assy Hardware
* = Not Shown
** = Optional, Not Included
RECOVERY TANK ASSEMBLY
12-1
