U.S. Products AGITATOR 16 User Manual

07-6
15
Agitator
™
16 / 18 Clean & Restore
FORM NO. 56041707
Item Ref. No. Qty Description
1 56244866 1 Cap, Raw (Agitator 18 Clean & Restore)
2 56453849 1 Bushing .26x.37x.28 (Agitator 18 Clean & Restore)
3 56692409 1 Cover Chain
4 832322 1 Cover-Solution Tank
5 1 Wsh, Flt SAE 1/4 (Agitator 18 Clean & Restore)
6 6 Scr, Pan Phil 10-24 X .62
7 1 Scr, Pan Phil 1/4-20 X .75 (Agitator 18 Clean & Restore)
8 1 Nut, Hex Nyl Loc SS 10-24
9 1 Scr, Pan Phil SS 10-24 X .50
10 1 Scr, Pan Phil Type A 10 X .50
11 56003753 1 Stud, 1/4-20 X 1.75 (Agitator 18 Clean & Restore)
12 1 Wsh, Flt SS .260 X 1.000 X .074 (Agitator 18 Clean & Restore)
13 56009111 1 Nut, Wing SS 1/4-20 (Agitator 18 Clean & Restore)
14 3 Clamp, Hose SAE #6
15 56262190 1 Barb
16 56264137 1 Screen
17 56265096 1 Vac Motor, 120v
* 56264453 1 Carbon Brush (set of 2) NOTE 1
18 56265202 1 Vac Hose Assy
19 56387302 1 Tube PVC .500X11.00 E00604
20 56266122 1 Tank, Solution, 16”
56266123 1 Tank, Solution, 18”
21 56266023 1 Chemical Tank Assembly (Agitator 18 Clean & Restore)
22 56266053 1 38 Mm Cap Assy, 90 X 1/4 Barb (Agitator 18 Clean & Restore)
23 56266056 1 Gasket, RS Strip (16”)
56266057 1 Gasket, RS Strip (18”)
24 56266058 1 Gasket, RS Strip
25 56266069 1 Lower Recovery Hose Assembly
26 56266072 1 Ergoex Belt Bracket
27 56266073 2 Grommet, Drain
28 56266094 1 Vacuum Motor Gasket
29 56314484 3 Mount, Vibration
30 56314617 1 Latch, Plastic (Agitator 18 Clean & Restore)
31 56314760 1 Gasket, Vacuum Duct
32 56331154 3 Clamp, Plastic
33 56386183 2 Barbed Elbow 90
34 56407267 1 Hose, Solution
35 1 Clamp, Hose SAE #32
36 54444a 1 USP Belt
** 11147A 1 Kit, Solution Tank Assy Hardware
* = Not Shown
** = Optional, Not Included
NOTE 1: Replacement parts for 56264453
SOLUTION TANK ASSEMBLY
13-6

U.S. Products AGITATOR 16 Specifications

General

Brand	U.S. Products
Model	AGITATOR 16
Category	Floor Machine
Language	English
