Part # 3052000 (09/16/09)Page 18
Pilot Burner Adjustments
General
1. Light the pilot light in accordance with the Operation
Instructions in Operation Section.
2. Check that the length of the ame and adjust as
necessary for desired characteristics. Screwdriver
adjustment may be made to the pilot valve adjacent
to the burner valve on the manifold, through the valve
panel opening.
Oven
1. Open the lower kick panel.
2. Remove the oven bottom assembly.
3. Light the pilot light in accordance with the Operations
Instructions.
4. Check that the length of the pilot light. Adjust pilot ame
for desired characteristics. Screwdriver adjustments may
be made to the pilot valve, adjacent to the oven burner
valve on the manifold, through the valve panel opening.
COMMISSIONING Continued
Solid Hot Plate/Griddle
1. Light the pilot in accordance with the Operation
Instructions.
2. Check that the length of the ame. Adjust pilot ame for
desired characteristics. Screwdriver adjustment may be
made to the pilot valve adjacent to the burner valve on
the manifold through the valve panel opening.
Front Fired Hot Top
1. Light the pilot light in accordance with the Operation
Instructions.
2. Check that the length of the ame. Adjust pilot ame for
desired characteristics. Screwdriver adjustment may be
made to the pilot valve adjacent to the burner valve on
the manifold through the valve panel opening.
Broiler
1. Light the pilot light in accordance with the Operation
Instructions.
2. Check that the length of the ame. Adjust pilot ame for
desired characteristics. Screwdriver adjustment may be
made to the pilot valve adjacent to the burner valve on
the manifold through the valve panel opening.
OPERATION
This section deals with equipment operating instructions
and some of the simple and obvious cleaning methods
that will help keep heavy duty cooking equipment in good
condition.
Open Top Burners
1. Open top burner pilots may be reached down through
the opening of the top grate.
2. Light the pilots.
3. Turn the valve completely on by rotating the knob to the
“ON” position.
NOTE: The burner ame should be a 1/2” stable ame and
impinge on the underside of a pot placed on the top grate.
Shutdown
1. Turn all valves to the o position.
2 If the unit is to be shut down for an extended time, close
the in-line gas valve.
Hot top and Spectro-Top Sections
1 Light the pilots via a long match or taper through the
opening in the valve panel.
2. Turn the burner valve on by rotating the knob to the “ON”
position. A sharp blue ame should be approximately
1/4” high.
