Part # 3052000 (09/16/09)Page 4
SPECIFICATIONS
Table A: Gas Pressures
SUPPLY GAS PRESSURE RANGE
Type Minimum Maximum
Natural 7” W.C.( 17.5 mbar) 14” W.C. (35 mbar)
Propane 11” W.C. (27.5 mbar) 14” W.C. (35 mbar)
MANIFOLD OPERATING PRESSURE
Type Natural Propane
Ranges, Broilers 6”W.C. (15 mbar) 10” W.C. (25 mbar)
Table B: Model Designations
MODELS DESCRIPTION
Standard Oven Base
C836-1 36” Griddle
C836-1-1 36” Thermostatic Griddle
C836-2 24” Griddle, (2) Open Burners (12” Top Grate)
C836-2-1 24” Therm. Griddle, (2) Open Burners (12” Top Grate)
C836-3 24” Griddle, 12” Hot Top
C836-3-1 24” Therm. Griddle, 12” Hot Top
C836-4 18” Griddle, (2) Open Burners (18” Top Grate)
C836-4-1 18” Therm. Griddle, (2) Open Burners (18” Top Grate)
C836-5 18” Griddle, 18” Hot Top
C836-5-1 18” Therm. Griddle, 18” Hot Top
C836-6 Six Open Burners – (3) 12” Top Grates
C836-6SU Six Open Burners (3 Are Step-up) – (6) Half Top Grates (12” Inch Wide Each)
C836-7 Four Open Burners (2) 18” Top Grates
C836-8 (3) 12” Hot Tops
C836-9 (2) 18” Hot Tops
C836-10 (2) Front Fired Hot Tops
C836-11 18” Hot Top (Left), Front Fired Hot Top (Right)
C836-11R 18” Front Fired Hot Top (Left) 18” Hot Top (Right)
C836-12 (2) Open Burners, 12” Top Grate (Left), 12” Hot Top (Centre), 12” Hot Top (Right)
C836-12C 12” Hot Top (Left), (2) Open Burners 12” Top Grate (Centre), 12” Tog Grate (Right)
C836-12R 12” Hot Top (Left), 12” Hot Top (Centre), (2) Open Burners, 12” Top Grate (Right)
C836-13L 12” Hot Top (Left), 2) Open Burners, 12” Top Grate (Centre), (2) Open Burners, 12” Top
C836-13C (2) Open Burners, 12” Top Grate (Left), (2) Open Burners, 12” Top Grate (Centre), 12” Hot
C836-13 (2) Open Burners, 12” Top Grate (Left), (2) Open Burners, 12” Top Grate (Centre), 12” Hot
C836-14 (2) Open Burners, 18” Top Grate (Left), 18” Hot Top (Right)
C836-14L 18” Hot Top (Left), (2) Open Burners, 18” Top Grate (Right)
C836-15 (3) 12” French Tops
