U.S. Range C836 SERIES - Broiler, Pilot Burner, and Oven Servicing

Part # 3052000 (09/16/09)Page 28
3. Clean the burners in hot soapy water with a sti
scrubbing brush.
4. Rinse the burners and shake them well to remove the
water.
5 Make sure the ports are free of debris. Clear ports of
debris if necessary.
6. Reassemble the burners in reverse order.
Standard Oven Burners
1. Remove the oven bottom assembly.
2. Remove the two screws that secure the front air shield in
place and lift out.
3. Slide the burner towards the rear, o the orice tting,
and remove from oven.
4. Clean the burner in hot soapy water with a sti scrubbing
brush.
5. Rinse the burner and shake it well to remove the water.
6. Make sure the ports are free of debris. Clear ports of
debris if necessary.
7. Reassemble the burners in reverse order.
RC Oven Burners
1. Open the lower front panel.
2. Remove the right hand oven door spring.
CAUTION: The oven door may need additional support to
remain closed.
3. Remove the right hand front radiation shield.
4. Slide the burner to the rear and o the orice. Then
slide it to the right and remove it from the combustion
chamber.
5. Clean the burner in hot soapy water with a sti scrubbing
brush.
6. Rinse the burners and shake them well to remove the
water.
7. Make sure the ports are free of debris. Clear ports of
debris if necessary.
8. Reassemble the burners in reverse order.
SERVICING Continued
Broiler
1 Remove the top grates.
2 Remove the briquettes or slide it to the rear and o the
orice.
3. Lift the rear of the burner and slide it to the rear and o
the oriface.
4. Clean the burners in hot soapy water with a sti
scrubbing brush.
5. Rinse the burners and shake them well to remove the
water.
6. Make sure the ports are free of debris. Clear ports of
debris if necessary.
7. Reassemble the burners in reverse order.
Pilot Burner Cleaning
Hot Plate/Solid Top/Griddle/Broiler
1. Remove the main burners. Refer to the appropriate
section on burner cleaning.
2. Disconnect the pilot gas supply pipe from the pilot
burner.
3. Remove the pilot burner.
4. Clean the pilot burner by blowing through it or washing
it.
CAUTION: Do not use wire to clear the pilot burner. It
might damage the unit.
5. Reassemble the pilot burner in reverse order.
Oven
1 On all models but RC (convection) units, remove the oven
bottom assembly. To deal with convection oven (RC)
models, follow the procedure specied below.
2. Remove the two screws securing the front air shield and
remove it from the oven.
3. Disconnect the pilot gas supply pipe.
