Pool Filter 300 - Pool Filter Set 300-2,5 m/h
1
Position 0
<WINTER>
Opens an air intake at the top of the lter that permits
the lter to be drained, rendering it free of liquids that
could freeze in the winter.
Position 4
<DRAIN>
Permits the water in
the swimming pool to drain.
Inow: PUMP
Drain: WASTE
Position 1
<FILTRATION>
Permits draining of swimming pool water. Water
circulates in tank.
Inow: PUMP
Outow: RETURN
Position 5
<CIRCULATION>
Permits the
circulation of water in the swimming pool
(helps dissolve water treatment chemicals).
Inow: PUMP
Outow: RETURN
Position 2
<RINSE>
Permits the rinsing of the sand, lowering the tank
pressure, so that the
silica sand at the bottom of the
tank can be cleared of mud.
Inow: PUMP
Outow: WASTE
Position 6
<CLOSED>
Permits the performance of maintenance work on
the lter.
Position 3
<FLUSH>
Permits the ushing
of the valve block to remove
accumulated residue.
Inow: PUMP
Drain: WASTE
NOTZE:
You will require a nipple and pipe extension, in order to use the WASTE drain.
EXPLANATIONS OF THE 4-WAY VALVE’S FUNCTIONS
CLEANING POOL FLOOR
Set the multi-port in the FILTRATION position to vacuum the pool oor (e.g. with Ubbink PoolCleaner Auto, Art. No.
7500401). Connect the pool oor vacuum hose to the skimmer. The ltration gro
up pump must be shut o.
Important: Fill the pool oor vacuum hose completely with water, so that the lter pump cannot take on air. Once
this has been completed, turn the pump on. If air enters the lter system, immediately shut the lter
pump o,
before again evacuating the vacuum of air.
Using the brush attachment, slowly and uniformly vacuum the oor of the pool to avoid stirring up dirt. A skimmer
with strainer basket is absolutely necessary if the ltration system does
not have a preliminary lter!
PRACTICAL INFORMATION FOR USE
The duration of the daily water ltration is the product of the ratio of your pool’s water volume (m³) to the volume of water owing through the lter p
er hour (m³/h) at an approx.
water temperature of 21° C.
If the ltration system runs for longer than four hours, it requires two hours to rest. Be careful to observe this, as it will p
rolong the life span of your pump.
(1) Required duration of the ltration:
Before and after season October - March
4 to 6 hours/day
+ 2 hours at night, if a pool cover is not used
Before season April - May
6 to 8 hours/day
+ 2 hours at night, if a pool cover is not used
Season June - Septe
mber
10 to 12 hours/day
+ 2 hours at night, if a pool cover is not used
Position 0
<WINTER>
Opens an air intake at the top of the lter that permits
the lter to be drained, rendering it free of liquids that
could freeze in the winter.
Position 2
<RINSE>
Permits the rinsing of the sand, lowering the tank
pressure, so that the silica sand at the bottom of the
tank can be cleared of mud.
Inow: PUMP
Outow: WASTE
Position 1
<FILTRATION>
Permits draining of swimming pool water.
Water circulates in tank.
Inow: PUMP
Outo
w: RETURN
Position 3
<FLUSH>
Permits the ushing of the valve block to remove
accumulated residue.
Inow: PUMP
Drain: WASTE
NOTE:
You will require a nipple and pipe extension, in order to use the WASTE drain.
