Ubee Interactive Using the WLAN Option
Ubee UBC1301-AA00 Advanced Wireless Voice Gateway Subscriber User Guide • March 2017 51
1. Connect a wireless client to the wireless UBC1301-AA00. Refer to Connecting a
Wireless Device on page 15 if needed.
2. Place the wireless client at around one meter (three feet) away from the UBC1301-
AA00.
3. Obtain the RSSI value for the connected client. This value is used in the formula
further below.
4. Use the following table to determine what materials the wireless signal must travel
through to reach the desired wireless coverage distance.
5. Use the following table to determine what materials the wireless signal must travel
through to reach the desired wireless coverage distance.
6. Use the attenuation value from the materials table above in the following formula:
Formula:
(Transmit Power, use -30dBm) – (Receiver Sensitivity, use RSSI value) =
Allowable Free Space Loss
Allowable Free Space Loss ÷ Materials Attenuation Value =
Optimal Distance in Feet Between the UBC1301-AA00 and a Wireless Client
Attenuation Considerations
Material
Attenuation
2.4GHZ 5GHz
Free Space 0.24dB / foot 0.3dB / foot
Interior Drywall 3dB to 4dB 3dB to 5dB
Cubicle Wall 2dB to 5dB 4dB to 9dB
Wood Door (Hollow/Solid) 3dB to 4dB 6dB to 7dB
Brick, Concrete Wall (Note 1) 6dB to 18dB 10dB to 30dB
Glass Window (not tinted) 2dB to 3dB 6dB to 8dB
Double Pane Coated Glass 13dB 20dB
Bullet Proof Glass 10dB 20dB
Steel / Fire Exit Door 13dB to 19dB 25dB to 32dB
Human Body 3dB 6dB
Trees (Note 2) 0.15dB / foot 0.3dB / foot
Note 1: Different types of concrete materials are used in different parts of the world and the thickness
and coating differ depending on whether it is used in floors, interior walls, or exterior walls.
Note 2: The attenuation caused by trees varies significantly depending upon the shape and thickness
of the foliage.

Ubee UBC1301-AA00 Specifications

General

Brand	Ubee
Model	UBC1301-AA00
Category	Gateway
Language	English
