Ubee UBC1329AA00 Advanced Wi-Fi 6 Voice Gateway User Manual • February 2021 15
3. Power on your PC. The PC must have an Ethernet network adapter or
Ethernet port and an Internet browser installed, such as Firefox or Internet
Explorer. The following browsers are supported:
• For Windows 2000, XP, Vista, Windows 10, Windows 8, Windows 7,
Google Chrome, Firefox 1.07 and higher, Internet Explorer v7 and
above, Netscape.
• For MAC OS X, 10.2, and higher: Firefox 1.07 and higher, Safari 1.x
and higher.
4. Connect the power adapter included in the product package to the
POWER port on the back of the cable modem and plug the other end into
the power outlet.
5. Connect the Ethernet cable included in the product package to your
computer’s Ethernet port. Connect the other end to one of the ETHERNET
ports on the back panel of the UBC1329AA00.
6. Connect a coaxial cable from the CABLE port on the back panel of the
device to the cable wall outlet, or to a cable splitter connected to the wall
outlet.
7. Connect an analog telephone (if you will be using the device for telephone
service) to the TEL1 or TEL2 port on the back panel of the device. Use an
RJ-11 telephone cable.
8. Validate the network connection using the device LEDs to confirm
operations.
• The PWR, DS/US, and ONLINE LEDs are solidly lit. Refer to LED
Behavior on page 6 for more information.
2.1.1 Wall Mount Installation
You can mount the UBC1329AA00 on a wall using the 2 mounting brackets on
the side of the device. Two round or pan head screws are recommended. See
the figure below.
D
