Ubee UBC1329AA00 Advanced Wi-Fi 6 Voice Gateway User Manual • February 2021 37
Label Description
More
When you click on more
, a description of the screen information is shown. Click
less
to shrink the description box again.
Wi-Fi Radio (2.4GHz) Select Enable or Disable for the 2.4GHz wireless radio band.
Wi-Fi Radio (5GHz) Select Enable or Disable for the 5GHz wireless radio band.
Private Wi-Fi Network
Name
This field displays the wireless network name, also called the SSID (service set
identifier) for the primary 2.4GHz and 5GHz radios. The wireless network name
will appear in the list of available wireless networks for the client device wishing
to connect. The default wireless network names are listed here, and are defined
as follows:
“WIFI” plus the last 6 characters of the gateway’s cable modem (CM) MAC
address (all in upper case). “-5G” is added when the 5GHz radio band is being
used. The primary SSIDs can be found on the device label.
Example primary SSIDs with cable modem MAC address 64:7C:34:FE:0D:17
2.4GHz: WIFIFE0D17
5GHz: WIFIFE0D17-5G
NOTE: You can change the primary network names to personalized ones. For
instructions refer to
Wi-Fi Edit 2.4GHz on page 40
Wi-Fi Edit 5GHz on page 45
If you change the SSID, the device does not revert to the default value when the
device is power cycled, but does revert to this default value if the device is reset
to factory defaults.
Frequency Band Lists the radio frequency band, 2.4GHz or 5GHz.
MAC Address Displays the wireless MAC addresses for each wireless interface.
Security Mode Displays the current security mode in use for each wireless band.
