Ubee UBC1329AA00 Advanced Wi-Fi 6 Voice Gateway User Manual • February 2021 42
Private Wi-Fi Network Configuration (2.4GHz)
Wireless
Network
Select Enable to turn on the 2.4GHz network, or select Disable to turn it off.
Network
Name
(SSID)
This field displays the wireless network name, also called the SSID (service set identifier) for
the primary 2.4GHz radio. The wireless network name will appear in the list of available
wireless networks for the client device wishing to connect. The default wireless network
name for the 2.4GHz network is defined as follows:
“WiFi” plus the last 6 characters of the gateway’s cable modem (CM) MAC address (all in
upper case).
Changing the Wireless Network Name:
You can change the primary network name to a personalized one. Highlight the old SSID
and delete.
Enter your personalized network name and then click Save Settings at the bottom of the
page.
NOTE: If you change the SSID, the device does not revert to the default value when the
device is power cycled, but does revert to this default value if the device is reset to factory
defaults.
Mode
Select the wireless networking standard (802.11 mode) to use. Only wireless clients that
support the networking protocol(s) you select are able to connect to the wireless network.
Available choices for the 2.4GHz radio are: 802.11n, 802.11g/n, 802.11b/g/n and
802.11b/g/n/ax (ax is Wi-Fi 6).
Label Description
