Uberhaus 87795021 - Window Installation Guide; Double-Hung Sash Window Installation

1. Cut the foam seal (adhesive type) to the proper
length and attach it to the window sill. See Fig.8
2. Attach the window slider kit to the window sill.
Adjust the length of the window slider kit according
to the width of window, shorten the adjustable window
kit if the width of window is less than 22.1 inches.
Open the window sash and place the window slider
kit on the window sill. Fig.9
3. Cut the foam seal (adhe
sive type) to the proper
length and attach it on the top of the window. See
Fig.10.
4. Close the window sash securely against the
window.
5. Cut the foam seal to an appropriate length and
seal the open gap between the top window sash
and outer window sash. See Fig.11.
Foam seal A
(adhesive type)
Window kit
Window sill
22.1
~ 38.6
Foam seal
Fig. 8
Fig.9
Fi g.10
Fig.11
Window kit
Window sill
INSTALLATION INSTRUCTIONS (optional)
Installation in a double-hung sash
window
9
