Installation in a sliding sash window
1. Cut the foam seal (adhesive type) to the proper
length and attach it to the window frame. See Fig.12.
2. Attach the window slider kit to the window sill.
Adjust the length of the window slider kit according
to the width of window, shorten the adjustable window
kit if the width of window is less than 22.1 inches.
Open the window sash and place the window slider
kit on the window sill. See Fig.13.
3. Cut the foam seal (adhesive type) to the proper
length and attach it o
n the top of the window.
See Fig.14.
4. Close the slidi
ng sash securely against the window.
5. Cut the foam seal to an appropriate length and
seal the open gap between the top window sash
and outer window sash. See Fig.15.
Foam seal
Foam seal A
(adhesive type)
Window
panel
Fig.12
Fig.13
Fig.14
Fig.15
INSTALLATION INSTRUCTIONS (optional)
10
22.1
~ 38.6
