Introduction
Thank you for purchasing the Ubiquiti Networks® Bullet
™
AC. This Quick Start Guide is designed to guide you through
installation and also includes warranty terms.
Package Contents
Dual-Band airMAX® ac Radio with
Dedicated Wi-Fi Management
Model: B-DB-AC
Bullet AC Compression
Seal
Quick Start Guide
Installation Requirements
• Shielded Category 5 (or above) cabling with drain wire
should be used for all outdoor wired Ethernet connections
and should be grounded through the AC ground of the PoE.
We recommend that you protect your networks from
harmful outdoor environments and destructive ESD events
with industrial‑grade, shielded Ethernet cable from Ubiquiti
Networks. For more details, visit
www.ubnt.com/toughcable
• Surge protection should be used for all outdoor installations.
We recommend that you use two Ethernet Surge Protectors,
model ETH‑SP, one near the B‑DB‑AC and the other at the
entry point to the building. The ETH‑SP will absorb power
surges and safely discharge them into the ground.
To LAN
To Antenna
ETH-SP
ETH-SP
ES-8-150W
B-DB-AC
TERMS OF USE: Ubiquiti radio devices must be professionally
installed. Shielded Ethernet cable and earth grounding must
be used as conditions of product warranty. TOUGHCable
™
is designed for outdoor installations. It is the professional
installer’s responsibility to follow local country regulations,
including operation within legal frequency channels, output
power, and Dynamic Frequency Selection (DFS) requirements.
