Ubiquiti EdgeRouter LITE User Manual

Wall Mounting
To mount the EdgeRouter Lite on a wall, you will need a drill, a
6mm drill bit, and a Phillips screwdriver.
1. Use a 6 mm drill bit to drill two holes 100 mm apart.
2. Insert the Screw Anchors into the holes. Use a Phillips
screwdriver to secure a Screw to each anchor. Leave a
clearance of approximately 3 mm between each screw
head and its anchor.
100 mm
3 mm
Note: You can also mount the EdgeRouter Lite in a
vertical orientation.
3. Position the EdgeRouter Lite with the Ethernet ports
facing down. Place the wall‑mount slots of the EdgeRouter
Lite over the screw heads on the wall. Then slide the
EdgeRouter Lite down to lock it into place.
12V DC

Ubiquiti EdgeRouter LITE Specifications

General

Processor	Dual-Core 500 MHz MIPS64
RAM	512 MB
Flash Storage	2 GB
Max Power Consumption	7 W
Operating System	EdgeOS
Operating Temperature	-10 to 45° C
Operating Humidity	10 to 90% Noncondensing
Certifications	CE, FCC, IC
Ports	3 Gigabit RJ45
Power Input	12V DC
Power Supply	External AC/DC Adapter
Routing Capacity	1 million packets per second (64-byte)
Power Method	External AC/DC Adapter
