5.2. Southern Hemispheres (SOU).
For Southern Hemisphere installations, ignore these(N, S,)
and face the solar panel to the North (and in a sunny
position,This ensures the solar cell receives as much sun as
possible and orients wind direction.) when installing the
Integrated outdoor transmitter.
Step 1: Install the Integrated outdoor transmitter and face the
solar panel North.
Step 2: Console operation is set to Southern Hemispheres
( SOU in the time area) in Location division.
Note: Console has to be location division setting so that
the directions on the sensor are matching with your real
location. Permanent wind direction error（read approximately
180º）will be introduced when the wind direction sensor is not
positioned correctly during installation.
First attach a pipe to a permanent structure and then attach
the sensor package to it . The U-Bolts will accommodate a
pipe diameter of 30-45mm (pipe not included), as shown in
Figure 14.
