Stainless Steel Mounting
Pole
Dimensions: Φ40 x 270mm
(Optional)
Figure 1
3.2 Recommend Tools
Precision screwdriver (for small Phillips screws)
Compass or GPS (for wind direction calibration)
Adjustable Wrench.
3.3 Sensor Assembly Set Up
Note: The outdoor sensor array must be powered and
updating before powering up the console, or the console will
stop scanning and connecting with the sensors.
The following illustration shows the full segment for
Thermo-Hygrometer，WIND,RAIN and UV INDEX sensor.
purposes only ,as shown in Figure 2.
