Udirc PEREGRINE User Manual

Picture 4
Mobile Phone Holder
Heading Hold ModeTake Off / Landing /
Emergency Stop Button
Strong/Weak Emission
Signal
Brief Introduction for Button Functions
Transmitter Battery
Indication
Forward / Backward
Trimming Indication
Left / Right Flying
Trimming Indication
Throttle Digital Display
Picture 5
Low /Medium /
High Speed
Left / Right Rudder
Trimming Indication
High / Medium /
Low Speed Mode
Left Stick
Right Stick
Left / Right
Rudder Trimmer
Forward / Backward
Trimmer
Left / Right
Flying Trimmer
Power Switch
Press down the Left Stick to switch to High / Medium / Low Speed
Move the Stick to forward / backward / left / right to fly the drone to up / down /
turn left / turn right.
Move the Stick to forward / backward / left / right to fly the drone to forward /
backward / left / right.
Press the button till the drone becomes balance if the drone if the drone rotates to the
left or right.
Press the button till the drone becomes balance if the drone if the drone drifts forward
or backward.
Press the button till the drone becomes balance if the drone if the drone tilts to the left
or right.
Move the power switch to the right to turn on the transmitter, and move to the left to
turn off.
Heading
Hold Mode
Press the button to enter heading hold mode, and press again to exit from heading
hold mode.
Take Off / Landing /
Emergency Stop
Button
Press the button and the drone will fly up automatically. Press the button again and the
drone will landing on the ground automatically. Press and hold the button more than 1s,
the drone propellers will stop and fall down immediately.
8
