4.Outdoor CPE Specification：
5. Connection Diagram:
5.1 . Transmitting Side:
Master control： AR9344
DRAM： DDR2 64MByte
FLASH：8MByte
Wired Interface：10/100Mbps LAN*2
CPE Transmission rate: 300Mbps (not network rate)
Transfer method: Direct Sequence Spread Spectrum (DSSS)
Modulation: OFDM/BPSK/QPSK/CCK/DQPSK/DBPSK
Network Standard：IEEE802.11n,IEEE802.11a ,IEEE802.3u
Supporting agreement: CSMA/CA TCP/IP,IPX/SPX,NetBEUI,DHCP,NDIS3,N-
DIS4,NDIS5
Frequency Range: 4900～6100MHz
Power consumption: ≤3W
Power scheme: POE 24V 1A
Antenna gain: 14DBi
Management settings：WEP management，Telnet，Serial
Encryption：WEP encryption 64/128bits, WPA, WPA2, 802.1x
Operating temperature：-30℃～65℃
03
Model: CPE450
