UeeVii CPE450 - LED Number to IP Address Mapping; Accessing and Setting CPE via PC; Power and Initial Network Connection

7. How to Access and Setting the CPE Via PC
6.5 LED Number & IP Chart:
LED A IP B IP 2.4G ID 5.8G ID
0 192.168.255.100 192.168.255.200 0
1 192.168.255.101 192.168.255.201 1
0
2 192.168.255.102 192.168.255.202 2
165
3 192.168.255.103 192.168.255.203 3
161
4 192.168.255.104 192.168.255.204 4
157
5 192.168.255.105 192.168.255.205 5
153
6 192.168.255.106 192.168.255.206 6
149
7 192.168.255.107 192.168.255.207 7
48
8 192.168.255.108 192.168.255.208 8
44
9
192.168.255.109 192.168.255.209 9
40
a 192.168.255.110 192.168.255.210 10
36
b 192.168.255.111 192.168.255.211 11
140
c 192.168.255.112 192.168.255.212 13
132
d 192.168.255.113 192.168.255.213 96
124
e 192.168.255.114 192.168.255.214 50
116
f 192.168.255.115 192.168.255.215 55
108
100
Step 1. Use a PoE adapter to power the wireless bridge through a network
cable. Pay attention to the "PoE" and "LAN" ports marked on the PoE adapter,
and power is supplied by POE instead of a DC power interface.
Step 2. Use a network cable to connect the CPE "LAN" port, connect the
network cable other ends to the PoE Adapter "POE" port, use another network
cable to connect to the "LAN" port of the PoE adapter, and connect the other
end of the network cable to the computer's "LAN" port.
Step Description:
