Page #3 background imageLoading...
Page #3 background image
3
FUNCTIONS
FEATURES
1000V AC/DC
10A AC/DC
Resistance 40MΩ
Diode test
Audible continuity
Capacitance 9999µF
T
emperature -328˚ to 2462˚F (-200˚ to 1350˚C)
Microamps
Milliamps
T
rue RMS
Auto/Manual ranging
Auto power off
Min/Max
Hold
1 ms Fast response Min/Max
Low battery indicator
Rubber boot
T
est lead holders
Kick stand
High resolution backlit display
Fused test lead inputs
Auto selection
GENERAL SPECIFICATIONS
Operating Temperature: 32˚ to 122˚F (0˚ to 50˚C)
Storage T
emperature: -44˚ to 122˚F (-20˚ to 50˚C)
Operating Humidity: <75% max.
Operating Altitude:
6561 ft (2000m)
Display:
6,000
Backlight:
Yes
Over
-range: “OL” is displayed
Dimensions:
6.49” x 3.3”x 2.17”
Item W
eight: 15.0 oz
Calibration:
Recommended annually
CAT Rating: CAT III 600V/CAT II 1000V
Certifications:
cELTus UL 61010-1:2012 3rd,
CE EN 61010-1:2010 3rd, IEC61010-2-033:2012 Ed.1, EN 61326-1:2013,
FCC, RoHS Compliant, TOV protection, IP 42, 6’ Drop protection
Battery T
ype: (AA) 2
Test Leads: CAT III test leads
Accuracy: ± (% of reading + # of least significant digits)
Measurement Category Short-Circuit (typical) kA
a
Location in the building installation
II < 10
Circuits connected to mains socket outlets and similar
points in the MAINS installation
III < 50 Mains distributions parts of the building
IV > 50 Source of the mains installation in the building
CATEGORY DEFINITIONS
