UfiSpace S9510-28DC - GNSS Interface Connection; 1 PPS Interface Connection

S9510-28DC Hardware Installation Guide | 24
Figure 37.
Connecting the 1PPS Interface
Connect an external 1PPS cable with an impedance of 50 ohms to the port labelled “ 1PPS”.
Figure 38.
Connecting the 10MHz Interface
Connect an external 10MHz cable with an impedance of 50 ohms to the port labelled "10MHz”.
Figure 39.
