8. Main Components Replaced during Overhaul
8.1 Main replaceable parts list
Table 6 Main replaceable parts list
Location No. Product name Standard size
Material
O’t
All models
Coupling
1
Coupling K5804 PU
1
Casing
2
O-ring S-6 NBR
1
3
O-ring S-24 NBR
1
4
O-ring S-55 NBR
1
5
O-ring JIS B 2401 V-160 NBR
1
Inlet port
6
O-ring JIS B 2401 P-24 NBR
1
No.1
intermediate
cover
7
Oil-seal HTC17-40-9 NBR
1
8
Oil-seal SCY17-30-7 FKM
1
9
Ball bearing 6203 SUJ
1
Front cover
10
Oil level gauge KW-1 PC
1
11
O-ring JIS B 2401 P-8 NBR
1
G-100D
Cylinder
12
Outlet valve
φ15×φ13×9
FPM
4
13
Outlet valve spring
φ10×22
SUS
4
Rotor
14
Vane spring
φ2.4×24
SWP
8
15
Intermediate pin
φ2×φ3.4×27
DRR
4
16
No.1 vane
62×15.5×t6
C
2
17
No.2 vane
20×14×t6
C
2
No.2
intermediate
cove
r
18
Oil seal SC15-30-7 FKM
1
19
Ball bearing 6002 SUJ
1
Gas ballast
valve
20
O-ring JIS B 2401 P-12 NBR
1
21
O-ring P-5 NBR
1
G-100S
Cylinder
22
Outlet valve
φ15×φ13×9
FPM
3
23
Outlet valve spring
φ10×22
SUS
3
Rotor
24
Vane spring
φ2.4×24
SWP
4
25
Intermediate pin
φ2×φ3.4×27
DRR
2
26
No.1 vane
62×15.5×t6
C
2
Side cover
27
Oil seal VC15-30-5 NBR
1
28
Ball bearing 6002 SUJ
1
Check valve
29
Oil supply valve
φ4×φ5×7.3
FPM
1
30
O-ring S-4 NBR
1
31
O-ring S-18 NBR
2
Note 1: Screws are all metric screws conforming to the ISO standard.
Note 2: For the relationship between components, see the assembly drawing.
