Ulvac MD 4U NT - Technical Data

Documents are only to be used and distributed completely and unchanged. It is strictly the users’ responsibility to check carefully
the validity of this document with respect to his product.
page 8 of 24
No. 47800-2-02-5
Technical data
We reserve the right for technical modications without prior notice!
Type MD 4U NT
Maximum pumping speed 50/60 Hz (ISO 21360) m
3
/h 3.8 / 4.3
Ultimate vacuum (absolute) without gas ballast mbar 1
Ultimate vacuum (absolute) with gas ballast mbar 3
Maximum permissible inlet pressure (absolute) bar 1.1
Maximum permissible outlet pressure (absolute) bar 1.1
Maximum permissible pressure (absolute) at
gas ballast valve
bar 1.2
Permissible ambient temperature
storage / operation
°C -10 to +60 / +10 to +40
Permissible relative atmospheric moisture during
operation
(no condensation)
% 30 to 85
Rated motor power kW 0.25
No-load speed 50/60 Hz min
-1
1500 / 1800
Maximum permissible range of supply voltage
(+/- 10% ) dual voltage motor
Attention: Observe specications on rating
plate!
100-115 V~ 50/60 Hz
120 V~ 60 Hz
200-230 V~ 50/60 Hz
Maximum rated current at:
100-115 V~ 50/60 Hz 120 V~ 60 Hz
200-230 V~ 50/60 Hz
A
A
5.7
3.0
Device fuse slow blow fuse 6.3A
Motor protection thermal cutout, manual reset
Degree of protection IEC 529 IP 40
Inlet small ange KF 16
Outlet silencer
Dimensions L x W x H approx. mm 325 x 239 x 198
Weight approx. kg 16.4
