page 9 of 24
No. 47800-2-02-5
Pump parts
Wetted parts
Gas inlet temperatures
Operating condition Inlet pressure
Permitted range of gas
temperatures at inlet
Continuous operation > 100 mbar (high gas load) +10°C to +40°C
Continuous operation < 100 mbar (low gas load) 0°C to +60°C
Short-time (< 5 minutes) < 100 mbar (low gas load) -10°C to +80°C
Components Wetted materials
Housing cover aluminium alloy (AlMgSi0.5 or AlSi12)
Head cover aluminium alloy (AlSi12)
Diaphragm clamping disc aluminium alloy (AlSi12)
Diaphragm FPM
Valves FPM
O-rings FPM
Connection tube aluminium alloy (AlMgSi0.5)
Small ange stainless steel
Silencer aluminium alloy / silicone
We reserve the right for technical modications without prior notice!
Position Component
1 Inlet
2 Outlet
3 Gas ballast valve
4 ON/OFF switch
5 Mains connection
6 Handle
7 Pump rating plate
8 Fan
9 Voltage changeover switch
