Connecting the Interface Card (For PC only)
Turn your computer’s power off and remove the computer’s housing cover. (Usually this will require
you to remove some screws from the back of your computer with a Phillips head screwdriver.)
Locate an available 16 bit ISA expansion slot. Remove the slot cover of that 16 bit slot so that you can
put in the included SCSI card.
Insert the SCSI card by pressing it gently but firmly into the slot. Make sure it is firmly seated into the
slot. (Remember to secure the SCSI card by using the screw from the slot cover.)
Replace the computer’s housing.
• The SCSI card that is supplied by UMAX is a proprietary card and will only support the
UMAX scanner. However, UMAX scanners are ADAPTEC compliant so they are
ADAPTEC compatible.
3
