SR6000, SR7000, SR9000: 2-Way Remote Start/Security/Keyless Entry System
4-Pin Harness on Realy Satellite
Wire Color Function
Pink (-) 200mA 3rd Ignition Output
Violet (-) 200mA 2nd Starter Output
Orange (-) 200mA 2nd Accessory Output
Blue (-) Status Output
3-Pin 2-Wire Door Lock Harness
Wire Color Function
Green (-) Lock, (+) Unlock Output
Empty
Blue (-) Unlock, (+) Lock Output
