User’s Manual UDP6900 Series Digital Control Power Supply
Instruments.uni-trend.com 15 / 44
3.3 Current Settings
The current range is between 0V to the maximum output. When press the current key , the cursor
indicator will move to the current field, as shown in the following figure.
The step of current settings is the same as the voltage settings.
3.4 Output ON/OFF
Press the output key to turn on the function and the indicator is green. The user’s page will highlight
to display the output voltage, current, ON/OFF state, power and output mode (CV/CC).
Explanation: Press the output key when the power supply is connected to the object under
test. Otherwise, it is easy to ignite when wiring. If the output function has been turned on but no
power output, please check the voltage settings and set the voltage and current to non-zero value,
and then turn on the output function.
