UT202A Operating Manual
Note:
When AC voltage measurement has been
completed, disconnect the connection between
the testing leads and the circuit under test and
remove testing leads from the input terminals.
C. Measuring Resistance (see gure 5)
Warning
To avoid damages to the Meter or to the
devices under test, disconnect circuit power and
discharge all the high-voltage capacitors before
measuring resistance.
To measure resistance, connect the Meter as
follows:
1. Insert the red test lead into the
terminal and the black test lead into the
COM terminal.
2. Set the rotary switch to ; resistance
measurement (Ω) is default or press
SELECT button to select Ω measurement
mode
3. Connect the test leads across with the object
being measured.
The measured value shows on the display.
Note:
To remove the objects being tested from
the circuit when measuring can obtain a more
accurate result.
When resistance measurement has been
completed, disconnect the connection between
the testing leads and the circuit under test and
remove testing leads from the input terminals.
Ω
