UNI-T UT33D User Manual

Measurement Operation (5)
C. DC Current Measurement (see figure 3)
Never attempt an in-circuit current
measurement where the voltage between
terminals and ground is greater than 60V.
If the fuse burns out during measurement,
the Meter may be damaged or the operator
himself may be hurt. Use proper terminals,
function, and range for the measurement.
When the testing leads are connected to
the current terminals, do not parallel them
across any circuit.
Warning
( figure 3)
17
Model UT33B/C/D: OPERATING MANUAL

UNI-T UT33D Specifications

General

Diode test	Yes
Product type	Digital multimeter
AC voltage range	200 - 500 V
DC current range	0.02 - 10 A
DC voltage range	0.2 - 500 V
Basic accuracy (DC current)	±(1%+2)
Basic accuracy (DC voltage)	±(0.5%+2)
Basic accuracy (resistance)	±(0.8%+2)
Dimensions (WxDxH)	73.5 x 35 x 130 mm
Battery voltage	9 V

Weight and Dimensions

Weight	156 g
