across the junction. A good silicon junction
drops between 0.5V and 0.8V.
To test a diode out of a circuit, connect the Meter as follows:
1. Insert the red test lead into the VΩmA terminal and the black test lead into the
COM terminal.
2. Set the rotary switch to (The Model: UT33B) or (The Model: UT33C/
UT33D)
3. For forward voltage drop readings on any semiconductor component, place the
red test lead on the component’s anode and place the black test lead on the
component’s cathode.
The measured value shows on the display.
Note
l In a circuit, a good diode should still produce a forward voltage drop reading of
0.5V to 0.8V; however, the reverse voltage drop reading can vary depending on
the resistance of other pathways between the probe tips.
Measurement Operation (11)
23
Model UT33B/C/D: OPERATING MANUAL

UNI-T UT33D Specifications

General

Diode test	Yes
Product type	Digital multimeter
AC voltage range	200 - 500 V
DC current range	0.02 - 10 A
DC voltage range	0.2 - 500 V
Basic accuracy (DC current)	±(1%+2)
Basic accuracy (DC voltage)	±(0.5%+2)
Basic accuracy (resistance)	±(0.8%+2)
Dimensions (WxDxH)	73.5 x 35 x 130 mm
Battery voltage	9 V

Weight and Dimensions

Weight	156 g
