13
If the insulation of the appliance is less than 2 MΩ, it will display “×” Insulation
as a FAIL
Final Result - Class 2
After the above tests are completed, the meter will indicate whether the
appliance has Passed or Failed the Class 2 test.
Testing an IEC Lead / Extension Lead / Cord Test
Plug the mains lead under test into the socket and the front panel mains socket on
the unit as Diagram 5
