UNI-T UT60B User Manual

l In the autorange mode, the Meter selects the best range for
input signals.
This allows you to switch test points without having to reset
the range.
l In the manual range mode, you may select the range.
This allows you to override autorange and lock the Meter in a
specific range.
The Meter defaults to the autorange mode in measurement
functions that have more than one range. When the Meter is in
the autorange mode,
To enter and exit the manual range mode:
1. Press RANGE.
The Meter enters the manual range mode and turns off.
Each presses of RANGE increments the range. When the
highest range is reached, The Meter wraps to the lowest
range.
Measurement Ranges (2)
Note
l If you manually change the measurement range after entering
the REL or Hold recording modes, the Meter exits these
modes.
l Under frequency/duty cycle and capacitance measurement,
only autorange mode is available.
2. To exit the manual range mode, press and hold RANGE for
two seconds.
The Meter returns to the autorange mode and is displayed.
is displayed.
13
Model UT60B/C/E: OPERATING MANUAL

UNI-T UT60B Specifications

General

Type	Digital Multimeter
Display	LCD
Display Count	1999
Diode	Yes
Continuity Buzzer	Yes
Transistor	Yes
Data Hold	Yes
Full Icon Display	Yes
Sleep Mode	Yes
Low Battery Indication	Yes
Input Impedance for DC Voltage Measurement	10MΩ
Power Supply	9V Battery
DC Current	200μA/2mA/20mA/200mA
Resistance	200Ω/2kΩ/20kΩ/200kΩ/2MΩ
Capacitance	20nF/200nF/2μF/20μF
Frequency	20kHz
Temperature	-40°C to 1000°C
