The Meter Structure (see figure 1)
(figure 1)
LCD Display
Functional Buttons
Rotary Switch
HzV Input Terminal:
Input for voltage, frequency/rpm, resistance, diode
and continuity measurements.
COM Input Terminal:
Return terminal for all measurements.
AmA Input Terminal:
Input for 0.1
A to 340.0mA current measurements.
10A Input Terminal:
Input for 0.01A to 10.00A current measurements.
1
2
3
4
5
6
7
Model UT60D: OPERATING MANUAL
