36
Model UT71C/D/E: OPERATING MANUAL
Figure 3-4. Continuity Test
Note
Open circuit voltage around –1.2V and range is 400
measurement range.
When continuity testing has been completed,
disconnect the connection between the testing leads
and the circuit under test and remove the test leads
away from the input terminals.
l
l
