Model UT71C/D/E: OPERATING MANUAL
C. DC Current
Range Resolution Accuracy Overload Protection
400µA
4000µA
40mA
400mA
10A
(0.1%+15)
(0.15%+15)
(0.5%+30)
0.5A, 250V, fast type fuse, 5×20mm
10A, 250V, fast type fuse, 5×20mm
Remarks:
l
l
When the measured current is 5A, continuous measurement is allowed.
When the measured current is between 5A-10A, continuous measurement 10 seconds and interval more than
15 minutes.
At 10A range:
0.01µA
0.1µA
0.001mA
0.01mA
0.001A
