Model UT71C/D/E: OPERATING MANUAL
K. 4~20 mA loop current
Range Resolution Accuracy Overload Protection
(4~20mA)% 0.5A, 250V, fast type fuse, 5×20mm(1%+50)0.01%
Remarks:
l
l
l
< 4mA, the primary display shows LO
4mA, the primary display shows 0% ….
20mA, the primary display shows 100%
> 20mA, the primary display shows HI
** END **
When the readings obtained is:
L. Power Measurement (UT71E only)
Range Resolution Accuracy Current Overload Protection
2500W
1000V
(2%+50)0.1W
Remarks:
l
l
l
Power factor input range: 0.00~1.00
Voltage input impedance: around 10M .
Voltage input range: AC50~250V
10A, 250V, fast type fuse, 5×20mm
Voltage Overload Protection
