Model UT804: OPERATING MANUAL
The Table 2-1 described each rotary switch position
V
mV
Table 2-1. Rotary Switch Selections
Rotary Switch
Position
DC voltage measurement
AC voltage measurement
DC millivoltage measurement
Resistance measurement
Capacitance measurement
Centigrade temperature measurement
AC or DC current measurement (400µA , 4000µA)
AC or DC current measurement (40mA , 400mA)
AC or DC current measurement (10A)
Rotary Switch Function Blue SELECT Function
None
None
lFrequency measurements
lDuty Cycle measurement
lDiode test lContinuity test
None
Fahrenheit temperature measurement
Toggle between AC or DC current
Toggle between AC or DC current
4~20mA loop current as % reading
Toggle between AC or DC current
V
Hz Duty
o
C
o
F
A
µ
mA %
A
