Model UT804: OPERATING MANUAL
Table 2-2. Functional Buttons
Functional Buttons
The buttons activate features that augment the function selected with the rotary switch.
The buttons are shown in Table 2-2.
Button Access MethodDescription
Press the button once.
Press and hold the button for
around 1 second.
Press the button once.
Press the button once.
Press the button once.
Press the button once.
SELECT feature:
Use the blue button to select any rotary switch alternate function
(labeled in blue letters)
LIGHT feature:
Under battery operated situation, turn the display backlight on.
Under AC operated situation, the backlight is always on, cannot
turn off.
Exit AUTO and enter MANUAL ranging. In MANUAL, select
next input range. Press EXIT to return to AUTO. AUTO is
default.
Store the current measurement value. Press EXIT to exit the
Store feature.
Recall the stored value. Press EXIT to exit the Recall feature.
Access Setup selections, the display shows “SET” flashing
In the Setup mode, each press of SETUP button steps to the
next Selection
