Edge Rise, fall, rise&fall
Pulse width trigger
Trigger mode
>、<、=
Polarity positive pulse width, negative pulse width
Pulse width range 20ns~10s
Video trigger (only UTD2025CL)
Trigger sensitivity (Typical) 2div Vpp
Signal model and line/field
frequency (video trigger
type)
Support standard NTSC and PAL, and the line number scope is respectively 1-525
(NTSC) and 1-625 (PAL)
Alternating trigger
Alter Edge, Pulse
Measurements
Cursor
Cursor Parameters
Voltage difference between cursors (△V),
Time difference between cursors (△T),
Reciprocal of △T (Hz) (1/△T))
Track Voltage value and time value of point of waveform
Automatic
measurement
Vpp, Vamp, Vmax, Vmin, Vtop, Vbase, Vmid, Average, Vrms, Overshoot, Preshoot, Frequency,
Period, RiseTime, FallTime, +Width, -Width, +Duty, -Duty, Delay
Math
Math operation +, -, ×, ÷
Window
Rectangle, Hanning、Blackman、Hamming
Sampling size 1024points
Trigger frequency meter
Reading resolution 6 bits
Trigger sensitivity ≤30Vrms
Accuracy (Typical) ±51ppm (+1 character)
Display
Displays types LCD with Diagonal of 178mm (7-inch)
Display resolution
UTD2025CL, UTD2052CL, UTD2102e：400 horizontal×RGB×240 vertical pixels
UTD2000EX Series：800 horizontal×RGB× 480 vertical pixels
Display color Color
Waveform luminance Adjustable (color)
