Service Manual UTS1000/3000 Series
Instruments.uni-trend.com 16 / 25
4. To reinstall, perform the above steps in reverse.
Removing the power module
The following procedure describes the removal and replacement of the rear cover assembly.
• To prevent electrostatic damage to components, wear a properly grounded antistatic wrist and foot
strap during installation, and use an antistatic mat in a tested antistatic environment.
• Remove the rear cover.
• Remove the rear cover assembly.
Steps:
1. Use a T10 Torque screwdriver to remove the 4 screws fixing the shielding cover, as shown in the figure
below:
2. Remove the power cord and fan wire, and then use a T10 Torque screwdriver to remove the 4 screws that
fix the shield, as shown in the figure below, and finally remove the power module;
3. To reinstall, perform the above steps in reverse.
Remove the fan
The following procedures describe fan removal and replacement.
• To prevent electrostatic damage to components, wear a properly grounded antistatic wrist and foot
strap during installation, and use an antistatic mat in a tested antistatic environment.
• Remove the rear cover.
• Remove the rear cover assembly.
