Rubber sealing caps
(Remove according to the type
Exhaust used:
HIGHER
- Split (remove both)
- Coaxial (leave only one shown)
REAR NOT VISIBLE
(rear in the boiler)
installation instructions in the kit.
it is possible only with coax
(Leave 2 above).
Departure Coaxial
(+) Adapter for double systems
Caution:
For exhaust congurations
Coaxial mount chimney spacer ‘’ E ‘’
provided with boiler
E
GENERAL INFORMATION ON THE FLUE GAS EXHAUST SYSTEM
It is recommended to only use original
Unical exhaust pipes.
The supplier will have no contractual
or extra-contractual liability for damage
caused due to incorrect installation and
use and in any case failure to comply
with the instructions provided by the
manufacturer.
NOTE!
For further details relating to pressure drops of
the individual components, for information on
standards, rules and regulations for proper ue
gas exhaust, refer to the "Technical Information"
section on the boiler page of the www.unicalag.
it website
