Unical KON 1 C24 User Manual

32
KON 1 C24
Type of
Gas
E󰀨ective
Output
[kW]
Heating
Thermal
[kW]
Capacity
Supply
Press.
[mbar]
Fan
speed
[rpm]
Collector
diaphragm
[Ø/n.
holes]
CO
2
levels
[%]
Con-
sumption
Con-
sumption
Start-up
power
IG [%]
min max min max min max
Nat. gas (G20) 2,9-22,6 3,0-23,4 20 1400 7000 8,8/12 9,5 9,5 0,32m³/h 2,47m³/h 50
Propane (G31) 4,2-22,6 4,4-23,4 37 1700 7000 8,8/12 10,5 10,5 0,34kg/h 1,82kg/h 35
(*) 8,9 ± 9,7 cceptable range for G20 (+) 10,0 ± 11,0 Acceptable range for G31
KON 1 C28
Type of
Gas
E󰀨ective
Output
[kW]
Heating
Thermal
[kW]
Capacity
Supply
Press.
[mbar]
Fan
speed
[rpm]
Collector
diaphragm
[Ø/n.
holes]
CO
2
levels
[%]
Con-
sumption
Con-
sumption
Start-up
power
IG [%]
min max min max min max
Nat. gas (G20) 4,3-27,2 4,4-28,0 20 1200 6200 9,8x25/6 9.3 9.3 0.47m³/h 2.96m³/h 60
Propane (G31) 5,4-27,2 5,6-28,0 37 1400 5900 9,8x25/6 10.5 10.5 0.43kg/h 2.17kg/h 60
(*) 8,9 ± 9,7 cceptable range for G20 (+) 10,0 ± 11,0 Acceptable range for G31
KON 1 C35
Type of
Gas
E󰀨ective
Output
[kW]
Heating
Thermal
[kW]
Capacity
Supply
Press.
[mbar]
Fan
speed
[rpm]
Collector
diaphragm
[Ø/n.
holes]
CO
2
levels
[%]
Con-
sumption
Con-
sumption
Start-up
power
IG [%]
min max min max min max
Nat. gas (G20) 4,3-32,0 4,4-33 20 1200 7000 9,8x25/6 9,3 9,3 0,47m³/h 3,5m³/h 50
Propane (G31) 5,4-32,0 5,6-33 37 1400 6800 9,8x25/6 10,5 10,5 0,43kg/h 2,56kg/h 50
(*) 8,9 ± 9,7 cceptable range for G20 (+) 10,0 ± 11,0 Acceptable range for G31
For proper operation, the CO
2
values
must be calibrated with particular at-
tention, observing the values indicated
in the table.
If the CO2 level detected is out of recommended range, verify the integrity of the electrode.
In case of necessity replace the electrode.
If the problem persists you can use the functions described below.
PRESSURE - FLOW RATES TABLE

Unical KON 1 C24 Specifications

General

Brand	Unical
Model	KON 1 C24
Category	Boiler
Language	English
