VX220
Specifications
Model No. VX220-TX VX220-RX
Component Units 1 x DX120-TX(Transmitter Unit) 1 x DX120-RX(Receiver Unit)
PC Connections 1 No
Connectors 2 x HDB15 Female
1 x Remote Out Jack
1 x USB Port (Type B)
1 x Mic. Out Jack
1 x Speaker In Jack
2 x RJ45
1 x DB9 (Female)
2 x HDB15 Female
1 x Remote In Jack
4 x USB Port (Type A)
1 x Mic. In Jack
1 x Speaker Out Jack
2 x RJ45
1 x DB9 (Male)
LEDs 2 x Power (Red), 2 x Link (Green)
Switch Button 2 x Momentary Switch, 1 x 3 Position Dip Switch
VGA Video Resolution 1920 x 1080@60Hz
Operation Temperature 0 ~ 40
o
C
Storage Temperature -20 ~ 60
o
C
Humidity 0~90% RH, Non-condensing
Weight 800g 890g
Dimension (L x W x H) 120 x 135 x 53.5 mm
Housing Metal enclosure
Power Adapter DC 9V
Safety / Emission FCC, CE
Features
• Extension distance up to 100M/ 330ft. over two Cat5e UTP cable segment
• Extending another 100M by adding the Gigabit Ethernet Switch through Cat5e cable between
Transmitter and Receiver Units.
• 4 x USB 2.0 Ports with USB extension over LAN for keyboard, mouse, RS232 and other USB devices.
• Support Audio and Mic. extension over LAN
• Each Video resolution can support up to 1920 x 1080
• Graphic Mode and Video Mode for selection
• Fully compatible with USB HID device for any keyboard, mouse and USB devices
• Supports multiplatform OS such as Windows 7/8/10/Linux and Mac OS X
• Optional IR remote control Unit accessories available
