4
Model 1200 Model 1201
Wavelength Range 325~1000 nm
Spectral Bandpass 5 nm
Wavelength Accuracy ± 2 nm
Wavelength Repeatability ± 1 nm
Stray Radiant Energy < 0.5%T at 340 and 400 nm
Photometric Range 0~125%T
0~2.0 Abs
0~1999C (0~1999 Factor)
Photometric Accuracy ± 1.0%T
Power Requirements 115/230 V ±10%, 60/50 Hz switchable
Sample Holder Single Test Tube/Cuvette 4-poisiton Cuvette Holder
Dimensions 415W x 320D x 175H (mm) (16-1/2 x13 x 6-3/4 inches)
Net Weight 6.5 kg (15 lbs)
Unpacking
Carefully unpack the contents and check the materials against the following packing list
to ensure that you have received everything in good condition.
Description Quantity
Model 1200 Model 1201
Spectrophotometer
1 1
Dust Cover
1 1
10 mm Optical Square Cuvette
2 2
Test Tubes (1/2 inch)
Box of 12 -
V-type Tube Holder (8 to 25 mm)
1 (installed) -
10 mm Single Cuvette Holder
1 -
Black Block
1 1
4-position Cuvette Holder
- 1 (installed)
Power Cord
1 1
User Manual
1 1
Installation
1. Place the instrument in a suitable location away from direct sunlight. To have the best
performance from your instrument, keep it as far as possible from any strong magnetic
or electrical fields or any electrical device that may generate high-frequency fields. Set
the unit up in an area that is free of dust, corrosive gases and strong vibrations.
2. Remove any obstructions or materials that could hinder the flow of air under and
around the instrument.
1200 and 1201 Spectrophotometer Operation Panel
